Specifications
|
|
Engine Type
|
Four cycle,
Single Cylinder, Liquid cooled |
|
Displacement |
249 c.c. |
|
Compression Ratio |
10.6:1 |
|
Carburetor |
Kei-Hin
with Manual Choke
|
|
Max. Power |
22.3Nm @
5500 rpm / 16.4bhp |
|
Ignition |
C.D.I. |
|
Battery capacity |
12V-9AH;
GTX12-BS |
|
Spark Plug |
CR8E
(NGK) |
|
Starting |
Electric / Kickstart |
|
Transmission |
Automatic (C.V.T. V-belt)
Manual Shift - Forward/Reverse |
|
Front Suspension |
Dual A-Arm Adjustable Shock @ 2.95" Travel |
|
Rear Suspension |
Swing Arm Adjustable Shock @ 4.72" Travel |
|
Front Brake |
Hydraulic Disc (2) |
|
Rear Brake |
Hydraulic Disc |
|
Front Tire |
21x7-10 |
|
Rear Tire |
22x11-9 |
|
Overall Dimensions
Length x Width x Height |
70.1 x
40.6" x 44.9" |
|
Wheelbase |
46.9" |
|
Dry Weight |
441 lbs |
|
Seat Height |
35" |
|
Ground Clearance |
5.9" |
|
Maximum Rider Weight |
330 lbs |
|
Fuel Tank Capacity |
12
liters / 3.17 Gal |
|
Color |
Red or Blue |
|
Optional Features |
Rear Cargo Rack (optional)
Headlights |
|
Warranty |
Full six months limited factory warranty |
